Zinc Sulfide
- Catalog Number
- ZI-5940
- CAS Number
- 1314-98-3
- Purity
- 99.99
- Formula Mass
- 97.47 g/mol
Product Description
Zinc Sulfide is available as 99.99 pure (metals basis) 1-2 micron powder, CVD grade granules or tablets, or as a nano-powder. Zinc Sulfide is available in large batch quantities for potential uses as a phosphor host, in optical coatings, or as an infrared window material. Lorad has developed a novel proprietary method for sintering Zinc Sulfide to high density.
- Market Focus: Security Phosphors, Thin Film Coatings, Polycrystalline Ceramics
- Categories: Sulfides
-
Product Notes:
ZnS powder at 1-2 microns is the source material for our tablets and granules for the vacuum evaporation of thin film coatings.
It should be noted that we also manufacture a range of very high purity zinc dialky dithiocarbamates, specially purified to be suitable for the chemical vapor deposition of zinc sulfide thin films. Lorad can provide user information to customers relating to the conditions for thin film growth, and the application of these precursors in an aerosol and conventional CVD source application.
- Zinc diethyldithiocarbamate
- Zinc ethylxanthate
Additional Properties & Information
| Typical Purity | 99.99 |
|---|---|
| Appearance | Zinc Sulfide powder is available in bulk as a high purity, (very low transition metals) 1-2 micron powder. Our 1-2 micron powder can be provided in CVD grade granules or as tablets. Zinc Sulfide is available as a nano-powder. |
| Density | 4.1 g/cm³ |
| Formula Mass | 97.47 g/mol |
| Melting Point | 1,850ºC |
Product Specifications
| Formula Mass | 97.47 g/mol |
|---|---|
| Purity | 99.99 |
| Density | 4.1 g/cm³ |
| Melting Point | 1,850ºC |
| Refractive Index | 2.35 at 550nm |
| Transmission Range | 380nm - 14µm |
| Evaporation Temperature | 1000 - 1100ºC |
| Evaporation Source | e-beam, Mo, Ta, Al<sub>2</sub>O<sub>3</sub> |
| Available as Granule | Yes |
| Available as Tablet | Yes |
Identifiers
| Formula | ZnS |
|---|---|
| CAS Number | 1314-98-3 |
| EC / List Number | 215-251-3 |
Safety Information
Applications
Potential applications as a phosphor host, in optical coating, or for infrared window material.
