Aluminum Fluoride
AlF3
- Catalog Number
- AL-0070
- CAS Number
- 7784-18-1
- Purity
- 99.99
- Formula Mass
- 83.98 g/mol
- Physical Form
- Fine powder in Kg to multi-Kg quantities, dense granules, tablets
Product Description
Aluminum Fluoride is available as a 99.99 pure (metals basis) powder for use in optical coatings applications. Aluminum Fluoride is also available as granules or tablets. Lorad Chemical uses a precise manufacturing process to produce large batch quantities of consistently high-purity powder for even the most sensitive applications.
- Market Focus: Lithium Ion Batteries, Thin Film Coatings, Fiber Optics, Crystal Growth
- Categories: Fluorides, Halides, High Purity Salts
- Synonyms: Aluminum trifluoride; Aluminium(III) fluoride
Additional Properties & Information
| Typical Purity | 99.99 |
|---|---|
| Appearance | Fine powder in Kg to multi-Kg quantities, dense granules, tablets |
| Density | 3.1 g/cm³ |
| Formula Mass | 83.98 g/mol |
| Melting Point | 1,291°C (anhydrous) (sublimes) |
| Crystal System | Rhombohedral |
Product Specifications
| Formula Mass | 83.98 g/mol |
|---|---|
| Purity | 99.99 |
| Density | 3.1 g/cm³ |
| Melting Point | 1,291°C (anhydrous) (sublimes) |
| Crystal System | Rhombohedral |
| Refractive Index | 1.36 at 550nm |
| Transmission Range | 200 - 8000nm |
| Evaporation Temperature | 800 - 1000ºC |
| Evaporation Source | e-beam, Mo, Ta |
| Available as Granule | Yes |
| Available as Tablet | Yes |
Identifiers
| Formula | AlF3 |
|---|---|
| CAS Number | 7784-18-1 |
| EC / List Number | 232-051-1 |
Safety Information
Applications
Lithium Ion Batteries
View application
Thin Film Coatings
View application
Fiber Optics
View application
Crystal Growth
View application
Dense granules and tablets can be used for high quality optical coatings.
This material may also be useful as a cathode material for lithium-ion batteries.
